UAW-15 SOLENOID VALVE 1/2" 240V - SC (Taiwan)


Bin No : 348076

Brand: SC (Taiwan)


29.200 KWD

(0 review)

Best Selling

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model

UAW-15

Size

½”

Cv

4

Orifice

17mm

Fluid

Temp C

5c-80c

Max. operating press. Kgl/cm2

Water

0.5-10

Air

0.5-15

Dimension

L

82

H

125

D

58

Weight

Kg

1.6



  • UAW series is multiplex-drive, pilot operated piston, conductive, and normally closed.
  • Valve body made of Cast Bronze.
  • Standard Voltage: 110VAC / 220VAC / 24VDC. (50/60HZ)
  • Customized voltage AC / DC are available.
  • Screwed end to BSPT. Option screwed: NPT, BSP Thread.
  • The pressure in excess of 15 kgf/cm² can be customized. (15~20kgf/cm²) Please define fluid type and working pressure when requested.
  • Normal working temperature: 80°C (NBR).
  • AC Voltage tolerance: ± 10% DC Voltage tolerance: ± 1%
