VERTICAL MULTI STAGE CENTRIFUGAL PUMP PVM 10-8 - PENTAIR (ITALY)

Bin No : 5210131

Brand: Pentair (Italy)

409.000 KWD

Out of Stock Login to save in Wish List

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model		PVM 10-8
Rated voltage		415 V Three phase
Motor power		4 hp (3 kW)
No load speed		2900 rpm
Connections	Inlet	2 inch
	Outlet	2 inch
Range of flow rate		5-13 m³/h
Max. operating pressure		25 bar
Min. input pressure		10 bar
Temperature of fluid		-15^oC to +120^oC
Ambient temperature		50^oC
Head of the pump		Cast iron (EN-GJL200 : ASTM 25B)
Pump head cover		Stainless steel
Impeller
Shaft
Outer sleeve
Chamber
O - ring for outer sleeve		EPDM
Collar		PTFE
Base		Cast iron
		Stainless steel
Insulation class		F
Protection degree		IP 55

Asynchronous electric motor with integrated stator and external ventilation
Flanged fittings with inlets and outlets of the same size
Main dimensions conform to DIN and IEC regulations
Equipped with high efficiency motors IE3 and a cartridge-type mechanical seal for easy maintainance
Applications:
