TEMPERATURE CONTROLLER - AUTONICS (KOREA)

Bin No : 350132

Brand: Autonics (Korea)

32.000 KWD

3 Items Available

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model	T4L-B4RK4C-N
Display method	4-digit 7-segment LED
Control method	ON / OFF control, P control
Input specification	Thermocouple: K(CA)
Sampling cycle	100 ms
Setting range	0 to 400℃
Control output	Relay (250 V AC~ 5 A)
Power supply	100-240 V AC~ 50/60 Hz
Display accuracy_thermocouple	•At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit •Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digit
Hysteresis	F.S. 0.2 to 3% variable
Proportional band	F.S. 1 to 10% variable
Proportional cycle	20 sec
RESET range	F.S. -3 to 3% variable
Environment_ambient temperature	-10 to 50℃, storage: -20 to 60℃
Environment_ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Weight	0.310 g
